SPC Calculator
Security design tool
Overview - Specify your intrusion security system with ease
The SPC intrusion system can provide you with many options for your security needs, we want to make this process of selecting the correct security configuration as easy for our customers as possible. Therefore, we have enhanced the SPC calculator to provide the ability to automatically select the correct components for your needs.
The SPC Calculator is designed to provide you with a tool to allow you to ensure that the security system has sufficient power to ensure the system remains operational should a mains failure occur. The Tool will also ensure that the system has sufficient current to supply the system and that the SPC system you choose has the capacity to support the required inputs. Each site can be defined with customer reference and the requirements for that site.
Power Overview
The power calculator will allow you to add the components to your system while visualizing the power usage and requirements of the system. Once the power and requirements are meet your SPC system will be stable and reliable. The power overview allows you to add components such as
- Keypads
- Modems
- PIR
- Detectors
- External bells
The system will also allow you to freely define components which you may wish to add
System Summary
The Summary element of the tool allows you to have an overview of the total elements on the system for example how many inputs were included, the summary we also highlight if the number of inputs exceeds the available for the system chosen.
Limit check
The Calculator will also verify a number of elements within the system to ensure that the SPC system you have chosen will meet your needs. The tool will verify
- Zones
- Expanders
- Keypads
- Users
- Doors
Additional Equipment
The Calculator will also you to add the additional components to your system including
- Magic detectors with frequency selection based on country
- Magnetic contacts
- GSM
- PSTN
- Flood detectors
- Glass break
- Seismic detectors
- Bells
Order Overview
For your convenience, we have added this section to the tool so that you may submit your order to your supplier.
So how does the wizard operate:
When you select the number of inputs, areas, users, doors, and keypads the system will select the correct SPC controller to support this number of zones and add the additional expanders for you. The system will then add sufficient output module to support the desired outputs required. The system will add keypads correspond to the grade for grade 3 and VDS systems the SPCK623 will be added for other systems the SPCK421 will be added.
The system will then balance the system adding in the required power supplies to power the system if you have selected grade 3 or VDS the system will add the SPCP333 or SPCP355.
For doors, the system will then add a door controller for each required door and a reader for each door, for VDS systems this will add the HFS-TKWA-APW/CDA2 and for other systems the VR50M-MF. The system will add power supply door controllers where required.
Finally, the system will add the required batteries and cable for the system. The end result of this is a system overview of the selected system and an order form. Customers can edit the tool to enter their price per component if they wish and also then can alter the part codes to match their systems.
The end result is a quick and easy tool for our customers to define a system based on the customers’ requirements.
Magnetic contacts
There are four fields for magnetic contacts for general expanders you can add flush (built in) magnet contacts or standard magnet contacts, you have the same options for the doors, these are separated so that the number of expanders and door controllers can be calculated correctly, the flush mount will add MK-2400-6 Magn. Cont.,6m, G2, alternatively the MK-2400-S1 contact will be added.
Wired Flood detectors
This will add the WM-2 Water detector to your system which is a direct current water probe for all conductive non-combustible liquids. For indoor applications.
Acoustic glass break detectors
For VDS and Grade 3 systems, the calculator will add the AGB800-AM Acoustic Glass Break G3, The AGB800-AM is a modern acoustic glass break detector, complete with anti-mask detection giving an alarm when the glass is broken due to attempted intrusion through doors, windows, and glazed walls.
The detector is based upon the latest technology and has internal filters to avoid unwanted alarms. The DRC Digital Room Compensation feature enables the detector to distinguish between glass breaking and general background noise.
For grade 2 systems the calculator will add AGB800 Acoustic Glass Break Detector G2
Wired passive glass break detectors
For all systems, the calculator will add the GB-5700-6 Glassbreak detector,6m,lam and the interface module (GB-5000-IN Relay-Interface for GB), The glass break-detector is specially developed for working on laminated glass area within a radius of 2 m under surveillance.
Wired Vibration sensors
For all systems, the calculator will add the ES400 Vibration detector. White, The ES400 shock detector can be mounted on window frames, doors, walls, ceilings, and floors for early detection of burglary attempts.
Sirens
For internal sirens, the calculator will add the Piccolo SO/Piccolo/BL/G3S5 (internal) for external the system will add the SIREXF Outdr. siren A2P3,110db,AL,flash
Pricing
In the Power overview, you can enter your own price and part codes which will be automatically included in the order summary.
Batteries
The Calculator will add the required batteries to the system, this will be for the controller and also any power supply expanders provided on the system.
Download
Please download the SPC Calculator here, please note you must enable macros in order to use the tool
